Main parameters

UNIT

    XK7118

 Main motor power

 kw

     0.75

 Maximum spindle speed

 rpm

     3000

 Z axis motor torque

 N.m

      6

 X axis motor torque

 N.m

      4

 Y axis motor torque

 N.m

      4

 Spindle taper

     BT30

 Table size

 mm

    650×180

 Table travel（X×Y×Z）

 mm

  300×130×220

 Distance from spindle axis to guideway surface

 mm

     230

 Distance from spindle nose to table surface

 mm

    35-270

 Allowance from spindle axis to table

 mm

    ≤0.02

 Overall dimension

 mm

 1000×850×1470

 Net weight

 kg

     560
