CNC CONTROL SYSTEM

KND1000M-C system has full reliable interlock,safety protection and malfunction diagnosis alarm functions,equipped with

standard corresponding  interface,it also can be connected with computer programs control and storage to complish CNC

machining.

Servo motor  X/Y/Z axis AC servo motor(torque:15N.M/15N.M/15N.M)

Power source :3 phase/AC 380V±10%  50Hz±10%

Use power capacity:15KVA

Coolant box volume:200L

Use air pressure:0.6MPa

MACHINE ACCESSORIES:

Cutter shank and draw bar: MAS-P40T-1

CUTTER SHANK BT40:

BT40 SHANK

Standard config:

1.       spindle unit 8000r.p.m

2.       cnc system:KND-1000M-C absolute value system;

3.       Spindle servo motor:maximum 8000r.p.m,11kw,torque:70N.m

X/Y/Z three axis servo motor 15N.M torque;

4.       BT40-16 DISC MAGAZINE(OPTIONAL);BT40-12T BAMBOO HAT MAGAZINE

5.       Rigid taping;

6.       Movable handwheel;

7.       Automatic centralized lubricant system;

8.       Z axis with balancing weight system

9.       External cooling system and water box;

10.   Oil-water separating equipment;

11.   Full guard and guide rail cover;

12.   Adjusting washer

13.   LED working lamp and alarm lamp;

Optional configuration:

1.       Foreign system: SIEMENS 828D OR 808D,MITSUBISHI M70B OR M701 OR FANUC 0I MD

2.       CHINESE SYSTEM:GSK ,KND OR HNC

3.       4^thaxis

Remark:due to configuration,special order,different cnc system and continuously improving,

Those would affect the some parts of the technical specifications,so please check all of them before

Order.If inconvenient,please understand!
