ZX7150A Drilling And Milling Machine
Product Name:
ZX7150A Drilling And Milling MachineModel No.:
ZX7150AMinimum Order:
1
Product Abstract:
ZX7150A 1: Spindle electromagnetic clutch feed, and digital drilling depth 2: Increase travel, span, the work surface 3: Enhanced spindle knife device can be configured to unload 4: Configure the table X to stepless feed, optional X, Y, Z coordinate digital 5: The guide surface and the main transmission parts centralized lubrication 6: Spindle box can be plus or minus 45 degrees rotation 7: Headstock Electric lift 8: cooling and protective devices 9: The electrical control cabinet with PIC main electrical components imported components
- Product Description
Model
ZX7150A
Tapping the largest diameter
45mm
Maximum drilling diameter
50mm
Maximum milling diameter
125mm
Distance of spindle center to column
360mm
Spindle nose to table distance
Minimum 180mm maximum 600mm
Spindle travel
200mm
Spindle taper hole
MT4
Spindle box lift travel
420mm
Vertical speed of the spindle box
1250mm/min
Maximum turning angle of the spindle box
Plus or minus 45 degrees
Spindle drilling speed range
38-1730r/min
Number of spindle speeds
12
Spindle automatic feed rate
0.1,0.2,0.3mm/r
Spindle automatic feed to the series
3 Level
Scale loop per revolution feed
102mm
Workbench X to the feed series
Stepless
Workbench X to the feed range
4-480mm/min
Workbench X to the fast-moving speed
640mm/min
Table area
350*1000mm
Workbench X / Y to travel
500*350mm
T-slot table size
3-14*100mm
Power of main motor
2.2,2.8 KW (double speed)
Motor power of the price rise
0.75kw
Cooling pump motor power
0.09kw
Workbench tool path parameters
220v，20nm
Weight of machine
1300kg
Maximum outline size of the machine
1550*1580*2210mm
