Product Abstract:

1. This machine is a square box body and multifunction drilling milling machine 2. Vertical milling machine and horizontal milling machine are gear drive 3. The torque transfer is dood, high processing efficiency, equipped with mechanical feed device, realizing the workbench longitudinal automatic feeding, reduce the labor intensity, improve the machine accuracy and surface finish. 4. Body rail quenching treat, with good abrasion resistance. 5. The milling head is installed on the front end of the sliding arm, can be moved back and forth, 6. Not only in the vertical plane within turning 45 degrees, but also on the body rotating 360 degrees, has Good processing universal property.


Product Description

Item

Unit

ZX6350ZA

Spindle taper



7:24 ISO40

Max Automatic Feed Drilling Diameter (for Casting Iron)

mm

8

Max Manual Drilling Diameter (for Casting Iron)

mm

50

Max Diameter of Vertical Millng Arbour

mm

25

Max diameter of boring hole

mm

120

Worktable size

mm

1250×320

Worktable travel(L/H/V)

mm

600/300/280

Vertical spindle nose to worktable

mm

90---370

Horizontal spindle centerline to worktable

mm

0---280

Vertical spindle centerline to vertical guideway

mm

200---550

Spindle speed range

r.p.m

(8 steps)60---1500(Vertical)
(12steps)30---1300(Horizontal)

Automatic Power Feed of X,Y Axis

mm/min

(8 steps) 15-370

Vertical Spindle Travel

mm

120

Worktable t-slot (nunmber/width/distance)

mm

3/14/70

Main motor

kw

1.5(Vertical)
2.2(Horizontal)

Worktable Automatic Power Feed Motor

w

750

Cooling Pmp Motor

w

40

Overall dimention

mm

1680×1480×2150

N.W/G.W

kg

1500/1600

Optional accessories:
DRO--on X, Y, Z--AXIS.
Universal dividing head.
Rotary worktable.
Clamping kit.
