Drilling And Milling Machine
Product Name:
Drilling And Milling MachineModel No.:
ZX7550CWMinimum Order:
1
Product Abstract:
Features: 1.Uses standardized assemblies from the VH milling machine universal use as milling machines and drill press 2.Easily shiftable gear drive ensures power transmission without losses 3.With V-belt spindle drive and gear spindle drive 4.Head swivels into the horizontal level on both sided via crank and toothed gear, easy activation of manual micro-feed for the spindle quill
- Product Description
SPECIFICATION
UNIT
ZX7550CW
Drilling capacity
mm
50
End milling capacity
mm
100
Vertical milling capacity
mm
25
Boring capacity
mm
120
Tapping capacity
mm
M16
Distance between spindle nose and worktable
mm
90-490
Range of spindle speed
r.p.m
115-1750(vertical) 60-1350(horizontal)
Spindle travel
mm
120
Table size
mm
1000 x 240
Table travel
mm
400 x 230
Overall dimensions
mm
1280 x 1100 x 2080
Motor power
kw
(vertical)0.85/1.5 (horizontal) 1.5
N.W/G.W
kg
850/1000
