Hydraulic Radial Drilling Machine
Product Name:
Hydraulic Radial Drilling MachineModel No.:
Z3050X16Minimum Order:
1
Product Abstract:
Z3050x16 Radial Drilling Machine is apply for the middle and big workpiece to drill hole,enlarge hole,reaming , mill surface,tapping and etc. It also can boring hole on the condition of good device. Z3050x16 radial drilling machine is improved on the based of new type machines. It is used widely.
- Product Description
This machine have many features as follows:
- Adopt hydraulic per-selection variable speed structure, it can save time.
- The spindle have positive and reverse ,stop,variable speed, neutral position and etc. All this operation can controlled by one handle, easily to operate.
- The spindle box,rocker arm,inner and outer column adopt diamond clamping structure with hydraulic drive. Clamping reliable.
- The rocker arm guideway,the surface of outer column, the spindle,the spindle quill,the inner and outer column . All these parts are dealt by quenching. This technology can keep the machine have good stability and prolong the machine’s life.
- Have prefect safety protection device and outer column’s protection.
- It also adopt a series of effective methods to keep the durable precision and life.
- This machine have perfect electrical device, so it can guarantee the user’s safety ,reliable.
Max. Drill diameter
50mm
Distance from spindle axis to column surface
350-1600mm
Traverse of spindle box
1250mm
Distance from spindle end to table surface
320-1220mm
Lifting traverse of rocker arm
580mm
Lifting speed of rocker arm
0.02m/second
Rotary angle of rocker arm
360°
Spindle taper
MT5
Spindle speed range
25-2000r/min
Spindle speed step
16 step
Spindle feed range
0.04-3.2mm/r
Spindle feed step
16 step
Spindle traverse
315mm
Drill depth of dial per rotary
122.5mm
Max. Torsional strength of spindle
490Nm
Max. Feed force of spindle
15680N
Main motor power
4kw
Motor power of lifting
1.5kw
Motor power of spindle box,vertical column,hydraulic clamping
0.75kw
Coolant power
0.09kw
Net weight
3500kg
Overall size
2500x1060x2655mm
