5H Rock Arm Milling Machine
Product Name:
5H Rock Arm Milling MachineModel No.:
5HMinimum Order:
1
Product Abstract:
5H machine is widely used for flat maching along with any tilt angle surface,it can work for milling slot,drilling,fraising,boring.The milling head can turn right and light ±90°,it can rotate with high speed and with wide speed range,it can carry out power feed with overload safe protective device.The spindle quill and machine guideway past special treatment,it has perfect appearance and excellent design structure,it is one ideal metal cutting machine.It can also install power feed and DRO depending on customer requirements.
- Product Description
Main specification
5H
Spindle taper
NT40
Spindle travel
127mm
Table size
1370 x 305 mm
Table travel(X,Y,Z)
750 (manual 850)x 400 x 400 mm
Distance from spindle nose to table surface
0-460 mm
Distance from spindle axis to column guideway surface
155-635 mm
Spindle speed range
16steps 80~3750 r.p.m
Max. Loading weight
350kg
Arm rotation
360°
Main motor power
3.7 KW（5HP POWER）
Coolant pump power
90 W
Tilt angle of vertical milling head
±90°(left and right)
±45°(front and rear)Overall dimension
1750×1650×2100mm
N.W/G.W
1250/1360 kg
