Y27 Series Four Column Hydraulic Press Machine

  • Four Column Slide Beam Hydraulic Press
  • HP Hydraulic Press Machine
  • HP-F Four Column Hydraulic Press
  • YQ32 Series Hydraulic Press
  • Y27 Series Four Column Hydraulic Press Machine


Product Description

Computer optimized structure:4-column,easy operation,economical,unility

Hydraulic controller adopt cartridge valve integerated system,act reliable,long life,less hydraulic impact,

reduce tube pipes and leak point,the  hydraulic integreated system use separated control unit.

Separated electrical control system,work reliable,visual,easy maintainance.

Centralized button control with adjusting,semi-auto(single-constant with fixed stroke and fixed pressure)two  operation way.

The working pressure,fast down idle stroke and slow pressing stroke of block all can be adjusted according to process requirement.

                        Specification                                                                               -                                                                                                   -Description                      Model          Y27-100 Y27-200 Y27-315 Y27-400 Y27-500 Y27-630
Unit
Norminal force KN 1000 2000 3150 4000 5000 6300
Return force KN 135 240 305 350 580 650
Slide stroke mm 500 710 800 800 900 900
Max.opening height mm 800 1120 1250 1250 1500 1500
Cushion force KN 400 800 1250 1250 2000 2000
Cushion return force KN 150 280 360 360 780 780
Cushion stroke KN 200 250 300 300 350 350
Slide speed Idle stroke mm/s 80 100 120 130 150 180
Working mm/s 7-15 7-18 5-12 4-10 7-15 5-12
Return mm/s 62 80 100 105 105 115
Cushion speed Eject mm/s 37 45 30 30 37 37
Return mm/s 80 90 100 100 95 95
Worktable availible area Left-Right mm 690 1000 1260 1250 1400 1600
Front-Rear mm 630 940 1160 1250 1400 1600
Cushion area Left-Right mm 350 650 820 820 970 1120
Front-Rear mm 350 650 820 820 970 1120
worktable's eject hole lay type and size Left-Right   150mmx2 total 3 column 150mmx4 total 5 column 150mmx5 total 6 column 150mmx5 total 6 column 150mmx6 total 7 column 150mmx7total 8 column
Front-Rear   150mmx2 total 3 rows 150mmx4 total 5 rows 150mmx5 total 6 rows 150mmx5 total 6 rows 150mmx6 total 7 rows 150mmx7total 8 rows
Hole dia. mm φ30 φ30 φ40 φ40 φ40 φ40
Overall dimension Left-Right mm 2600 3300 3600 3800 4000 4300
Front-Rear mm 1400 1350 1600 1700 2100 2100
Height above floor mm 3100 4280 5000 5300 5100 5400
Height below ground level mm 300 350 1000 1000 1250 1300
Main motor power   KW 7.5 11 18.5 22 15x2 22x2
