Vertical Milling Machine
Product Name:
Vertical Milling MachineModel No.:
X5040Minimum Order:
1
Product Abstract:
This machine one more powerful metal cutting machine,it has high rigidity,wide range of spindle feed also can bear a heavy burden.The spindle taper hole can install many kinds of cylindrical cutter,disc cutter,form cutter,end milling cutter and so on,it is suitable for maching all parts plane,inclined plane,groove,hole etc,it is one ideal maching equipment for machinery manufacturering,mould,apparatus,instrument,car and motor car.
- Product Description
X5040 Milling Machine, has extra travel in longitudinal, operating control adopts a cantilever panel. It is suit for milling flat, inclined face, angular surface, slots by employing disc cutters, angular cutters. When mounted with the index, the machine will be able to perform milling operations in gears, cutter, helix groove, cam and tub wheel.
Vertical milling head can be swiveled by ± 45° . Spindle quill can be moved in vertical. The longitudinal, cross and vertical movements of the table can both be operated by hand and power, and it can be rapid moved. Working table and slide ways adopted quality cast hardened ensure high accuracy.
Machine features:- Rectangular guideways;
- Hardened and ground table surface;
- Spindle swivels +/-45 degrees;
- Quill moves up and down
Main specification
X5032
X5040
Table size
320 x 1325 mm
400 x 1700 mm
Spindle taper
7:24 ISO 50
7:24 ISO 50
Spindle bore
29 mm
29 mm
Distance from spindle nose to table surface
60-410 mm
30-500 mm
Distance from spindle axis to bed vertical guideway surface
350 mm
450 mm
T-slot(number/width/spacing)
3/18/70
3/18/90
Table max. longitudinal travel manual/automatic
700/680 mm
900/880 mm
Table max. cross travel manual/automatic
255/240 mm
315/300 mm
Table max. vertical travel manual/automatic
350/330 mm
385/365 mm
Table rapid speed longitudinal/cross/vertical
2300/1540/770 mm/min
2300/1540/770 mm/min
Max. turning angle of vertical milling head
±45°
±45°
Spindle travel
70 mm
85 mm
Number of spindle speed
18(steps)
18(steps)
Spindle speed range
30~1500 r.p.m
30~1500 r.p.m
Number of table feed
18(steps)
18(steps)
Main motor power
7.5 KW
11 KW
Feed motor power
2.2 KW
3 KW
Overall dimension
2294 x 1770 x 1904
2556×2159×2258
Net weight/Gross weight
2900 kg/3200kg
4250 KG/4350KG
