Radial Arm Milling Machine X6325

  • Universal Milling Machine X6332C
  • X6336 Universal Milling MACHINE
  • Radial Arm Milling Machine X6325
  • Universal Milling Machine XQ6232WA
  • Universal Milling Machine LM-1450A
  • Universal Milling Machine LM-1450A
  • Universal Milling Machine LM-1450A
  • Universal Milling Machine LM-1450A

Product Abstract:

X6325 X6325A X6325B X6325C X6325D Universal Radial Milling Machine has reasonable construction and superior machining functions such as drilling, boring, milling of plane, inclined plane and slot, and such functions available by use of the corresponding attachments as milling of helix slot, round surface, rack, gear and spline


Product Description

Features of X6325 X6325A X6325B X6325C X6325D Universal Radial Milling Machine

1. X6325 Universal Radial Milling Machine Rectangular guide way on Y-axis and Z-axis is featured a good rigidity

and stability, The guide way on Radial Milling Machine saddle is lined with TF wearable material

2. X6325A Universal Radial Milling Machine: Double 55° dovetail guide way is adopted on both Y-axis and Z-axis;

X6325B Radial Universal Milling Machine: Rectangular guideway on Y-axis and dovetail 55°guide way on Z-axis

makes the X6325B Universal Radial Milling Machine stably and easy to adjust;

X6325A, X6325B guide way on saddle is lined with TF wearable material. So it is easy to adjust;

X6325A, X6325B worktable surface and 3 axis guide way are hardened and precision ground;

3. X6325C Radial Universal Milling Machine: Rectangular guide way on Y-axis and Z-axis is featured a good rigidity

and stability, X6325C Universal Radial Milling Machine guide way on X6325C saddle is lined with TF wearable material;

4. X6325D Universal Radial Milling Machine: Rectangular guideway is adopted on Y-axis and Z-axis; X6325D Universal

Radial Milling Machine guide way on saddle is lined with TF wearable material which made the machine stably and

rigidly, also make X6325D beautiful and easy to operate



pecifications of X6325 X6325A X6325B X6325C X6325D Universal Radial Milling Machine



Model

Unit

X6325

X6325A

X6325B

X6325C

X6325D

Table size

mm

254x1270(10''x50''); 254x1370(10''x54'')

Long travel

mm

850; 950

Cross travel

mm

420

400

420

Vertical travel

mm

420

T-slot No.and sixe

mm

3x16

Ram travel

mm

470

Distance from spindel nose totable surface

mm

0-420

Spindle hole taper



Standard: R8; Optional: ISO30/ISO40

Standard: ISO40

Spindle travel

mm

127

Spindle speed

rpm

Standard: shift grade 16  50HZ:65-4500 / 60HZ:80-5440

Optional: variable 65-4500

Optional: variable 65-3750

Auto.quill feed

mm/rev

three steps 0.04(0.0015")/ 0.08(0.003")/0.15(0.006")

Spindle motor

kW

2.25 (3HP)

3.75 (5HP)

Head swivel



90°

Head tilting



45°

45°

45°

Fix

45°

Dimension of package

One per case

mm

1516x1550x2080

Two per case

mm

1650x1790x2170

Three per case

mm

1650x2285x2235

weight

kg

1550

1380

1420

1590

1590
