Table size

150x460mm(6x18”)

Max.grinding length

475mm(18-3/4”)

Max.grinding width

160mm(6-1/3”)

Distance from table surface to spindle center

400mm(15-3/4”)

Standard magnetic chuck size

150x400mm(6x16”)

Cross traverse Feed/Manual travel

465mm(19”)

Longitudinal Movement/Manual travel

180mm(7”)

Handwheel per graduation

0.02mm(0.008”)

Handwheel per revolution

5mm(1/5”)

Vertical Downfeed/Handwheel per graduation

0.005mm(0.0002”)

Handwheel per graduation

1mm(0.005”)

Wheel size (dia. x width x bore)

180x16x32mm/(7”x2/3”x1-1/4”)

Spindle speeds(50HZ/60HZ)

3000/3600rpm

Spindle motor

1或1.5HP

Net

720kg(1584lbs)

Gross

850kgs(1870lbs)

Parking  Size(Length x width x height)

1400x1150x1980mm(55x45x78”)
