Specification

Units

X6140

Table size

mm

1700x400

No.of T-slots

3

Width of T-slots

mm

18

Max.load

kg

800

Longitudinal
travel(manual/auto)

mm

900/800

Cross travel
(manual/auto)

mm

315/300

Vertical travel
(manual/auto)

mm

380/360

Cutting feed speed

mm/min

X:19--950  Y:19--950
Z:6.3--317

Rapid feed speed

mm/min

X-2300  Y-2300  Z-770

Spindle speed range

r/mm

30-1500

Spindle speed step

-

18 (steps)

Distance between spindle
axis table surface

mm

30~410

Power of spindle motor

kw

11

Overall dimension(LxWxH)

mm

2556x2159x1770

Net weight

kg

3850
