Air Hammer Single With Base Plate C41-25DB

  • Air Forging Hammer
  • Power Hammer
  • Air Hammer Single With Base Plate C41-25DB

Product Abstract:

The series of air hammer with small size,low noise,simple structure,easy operation,flexible movement and convenient to transit,installation,maintenance,the type is widely used for various of free Forging works, such as drawing-out, upsetting, punching, chiseling, forging welding, bending and twisting. It is also used for forging in bolster dies.It is suitable for free forging works of all kinds of different shape parts.


Product Description
SPECIFICATION UNIT C41-25DB
Max. hit energy kj 0.27
Height of working area mm 240
Hit number  min-1 250
Dimension of top and bottom die surface(LxW) mm 100 x 50
Max. square steel can be forged mm 40 x 40
Max. round steel can be forged(Diameter) mm ¢45
Motor  power kw single phase 3/220V
three phase 2.2/380V
Speeds of motor r.p.m 1440
Base plate weight kg 80
Total weight kg 840
Overall dimensions(L*W*H) mm 1150*510*1400
